Corsair FRAME 5000D WORKSTATION Modular Mid-Tower PC Case

Modular mid-tower engineering for workstation-class builds | Expansive cooling and radiator support | Reverse-connector motherboard compatibility | Tempered glass showcase panel | Comprehensive hardware accessory kit included

Quick Specs

• Achieve extreme build flexibility with support for Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, and SSI-EEB motherboards.
• House the most powerful GPUs with up to 450mm of clearance and a dedicated anti-sag stabilisation arm.
• Dominate thermal management with radiator support up to 420mm across the front, top, and side simultaneously.
• Connect everything instantly with front I/O including USB 3.2 Gen 2x2 Type-C and four USB 3.2 Gen 1 Type-A ports.
• Build with confidence across 9 expansion slots and 42mm of rear cable-routing space for a clean, professional finish.

A Clean Build Platform with Pro-Grade Connectivity

The FRAME 5000D keeps cable management organised with 42mm of rear cable-routing space, RapidRoute cable management, and 12 zip ties included in the accessory kit. Dust filters on the front, side, and bottom protect your components in long-term operation. The front I/O panel delivers four USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2x2 Type-C port, and a combined mic/headphone jack for day-to-day connectivity. The 3D-Y Airflow Steel front panel and steel side panels — with sound dampening material — round out a chassis that is as practical as it is purposeful.

Features

• Supports Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm), SSI-CEB, and SSI-EEB motherboards, including reverse-connector designs.
• Radiator support up to 420mm at the front, top, and side — with 120mm and 140mm rear radiator support as well.
• Maximum GPU length of 450mm (425mm with fans installed); GPU anti-sag stabilisation arm and rubber spacer included.
• 175mm maximum CPU cooler height clearance for compatibility with large tower coolers.
• 8 horizontal + 3 vertical PCI expansion slots for multi-GPU and high-expansion workstation configurations.
• Front I/O: 4x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2x2 Type-C, 1x combo mic/headphone jack.
• 42mm rear cable-routing space with RapidRoute cable management system.
• Dust filters on the front, side, and bottom; tempered glass left side panel for interior visibility.
• Steel side panels with sound dampening material for reduced acoustic output.
• Pre-installed 12x InfiniRail fan mounts for flexible, tool-friendly fan and radiator positioning.

Specifications

• Brand: Corsair
• Motherboard Support: Mini-ITX, Micro-ATX, ATX, E-ATX
• Side Panel: Tempered Glass
• Included Fans: 4
• Max GPU Length: 450 mm
• Max CPU Cooler Height: 175 mm
• Radiator Support:
  • Front: 240mm, 280mm, 360mm, 420mm,
  • Top: 240mm, 280mm, 360mm, 420mm,
  • Rear: 120mm, 140mm,
  • Side: 240mm, 280mm, 360mm, 420mm,
  • PSU Shroud: None
• Front I/O:
  • 4x USB 3.2 Gen 1 Type-A,
  • 1x USB 3.2 Gen 2
  • x2 Type-C,
  • 1x Power Button,
  • 1x Combo Mic / Headphone
• RGB Lighting: false
• PSU Included: false

What's in the Box

• 1 x Corsair FRAME 5000D WORKSTATION Mid-Tower PC Case - Black
• 1 x Side Fan Mounting Bracket
• 1 x Reverse Connector Magnetic Strip
• 12 x InfiniRail Fan Mounts (pre-installed)
• 1 x Front I/O Adapter
• 12 x Zip Ties
• 16 x QuikTurn Fan Screws
• 8 x Long Fan Screws
• 18 x Motherboard / HDD Screws
• 16 x SSD Screws
• 1 x Spare Motherboard Standoff
• 2 x Vertical Mount Standoffs
• 12 x InfiniRail Fan Mount Lock Screws
• 1 x Anti-Sag Arm Rubber Spacer
• 1 x GPU Anti-Sag Stabilisation Arm Mini Mount
• 1 x CORSAIR Side Cable Shroud Sticker
